一，TYPICAL CHARACTERISTICS
| Typical characteristics IPV | |||||||
| Type,size - delivery | Displacement per revolution | Speed n | Delivery | Pressures | |||
| min. | max. | at 1500 min-1 | Continous pressure within the range nmin- nmax | Peak pressure within the range nmin- 1500 min-1 | Peak pressure within the range nmax | ||
| [cm3] | [min-1] | [min-1] | [l/min] | [bar] | [bar] | ||
| IPV 3－3.5 | 3.6 | 400 | 3600 | 5.4 | 330 | 345 | 345 |
| IPV 3－5 | 5.2 | 400 | 3600 | 7.8 | 330 | 345 | 345 |
| IPV 3－6.3 | 6.4 | 400 | 3600 | 9.6 | 330 | 345 | 345 |
| IPV 3－8 | 8.2 | 400 | 3600 | 12.3 | 330 | 345 | 345 |
| IPV 3－10 | 10.2 | 400 | 3600 | 15.3 | 330 | 345 | 345 |
| IPV 4－13 | 13.3 | 400 | 3600 | 19.9 | 330 | 345 | 345 |
| IPV 4－16 | 15.8 | 400 | 3400 | 23.7 | 330 | 345 | 345 |
| IPV 4－20 | 20.7 | 400 | 3200 | 31 | 330 | 345 | 345 |
| IPV 4－25 | 25.4 | 400 | 3000 | 38.1 | 300 | 330 | 330 |
| IPV 4－32 | 32.6 | 400 | 2800 | 48.9 | 250 | 280 | 280 |
| IPV 5－32 | 33.1 | 400 | 3000 | 49.6 | 315 | 345 | 315 |
| IPV 5－40 | 41 | 400 | 2800 | 61.5 | 315 | 345 | 315 |
| IPV 5－50 | 50.3 | 400 | 2500 | 75.4 | 280 | 315 | 280 |
| IPV 5－64 | 64.9 | 400 | 2200 | 97.3 | 230 | 250 | 250 |
| IPV 6－64 | 64.1 | 400 | 2600 | 96.1 | 300 | 330 | 300 |
| IPV 6－80 | 80.7 | 400 | 2400 | 121 | 280 | 315 | 280 |
| IPV 6－100 | 101.3 | 400 | 2100 | 151.9 | 250 | 300 | 270 |
| IPV 6－125 | 126.2 | 400 | 1800 | 189.3 | 210 | 250 | 250 |
| IPV 7－125 | 125.8 | 400 | 2200 | 188.7 | 300 | 330 | 300 |
| IPV 7－160 | 160.8 | 400 | 2000 | 241.2 | 280 | 315 | 280 |
| IPV 7－200 | 202.7 | 400 | 1800 | 304 | 250 | 300 | 270 |
| IPV 7－250 | 251.7 | 400 | 1800 | 377.5 | 210 | 250 | 250 |
二，TYPICAL MODELS
IPV3-3.5-100，IPV3-3.5-101，IPV3-5-100，IPV3-5-101，IPV3-6.3-100，IPV3-6.3-101，IPV3-8-100，IPV3-8-101，IPV3-10-100，IPV3-10-101，
IPV4-13-100，IPV4-13-101，IPV4-16-100，IPV4-16-101，IPV4-20-100，IPV4-20-101，IPV4-25-100，IPV4-25-101，IPV4-32-100,IPV4-32-101，
IPV5-40-100，IPV5-40-101，IPV5-50-100，IPV5-50-101，IPV5-64-100，IPV5-64-101，
IPV6-64-100，IPV6-64-101，IPV6-80-100，IPV6-80-101，IPV6-100-100，IPV6-100-101，IPV6-125-100，IPV6-125-101，
IPV7-125-100，IPV7-125-101，IPV7-160-101，IPV7-160-111，IPV7-200-101，IPV7-200-111，IPV7-250-101,IPV7-250-111
